Measurement Range: 0-250 PSI, optimized for precise pressure testing in industrial applications like gas utilities and pipeline integrity checks.
Precision Measurement: High-accuracy readings suitable for regulatory compliance, surpassing traditional analog gauges in reliability and detail.
Multiple Units of Measure: Supports 11 pressure units for versatile use: PSI, bar, mbar, kPa, MPa, inHg, mmHg, Torr, inH₂O, mH₂O, and kg/cm².
Pressure Percentage Indicator: Displays pressure as a percentage of the full-scale range, helping users quickly assess relative levels during tests.
High and Low Peak Value Recording: Automatically captures maximum and minimum pressure values during tests for performance analysis and anomaly detection.
Built-in Data Logging: Onboard recording of pressure data over time, enabling detailed test histories without external devices.
High-Capacity Storage: Records up to 86,400 data points per session, ideal for extended monitoring in field operations.
Configurable Recording Intervals: Adjustable from 1 second to 1 hour, allowing customization based on test duration and detail needs.
VeriGauge Reports App: Streamline pressure testing with powerful reporting, generating customizable reports from up to 86,400 logged data points, verified calibration certificates for compliance, and automated calibration reminders to ensure accuracy. Discover more at VeriGauge Web App.
Intuitive User Interface: Simple button-based navigation (e.g., LIGHT, ZERO, MENU buttons) for easy menu access, threshold setting, and operation, even in field conditions.
Configurable High and Low Alerts: User-settable pressure thresholds that trigger visual alarms (e.g., on-screen indicators) if values spike or drop outside parameters, ideal for real-time leak detection in pipe sections.
Visual Alarm Indicators: On-device alerts (e.g., dashes or icons) for active alarm states, providing immediate feedback during tests without needing additional tools.
Menu-Driven Alarm Setup: Dedicated screens (e.g., MIN/MAX menus) for toggling alarms on/off and fine-tuning thresholds, with display showing prior settings or defaults for quick reconfiguration.
Configurable Backlight Function: Offers continuous illumination or customizable auto-off timeframes for energy efficiency and improved visibility in low-light environments.
Rechargeable Li-Ion Battery: Long-lasting power source providing over 100 hours of operation per charge, with efficient charging for minimal downtime.
USB Type-C Port: Enables fast charging and seamless data transfer to external devices, supporting easy export of logged test results.
Mobile Data Upload and Reporting: Effortlessly upload and save logged pressure data to mobile devices via USB Type-C or the VeriGauge Reports App*, enabling on-the-go report backup, creation and real-time test analysis in the field.
Out-of-Calibration Lock-Out: Automatically blocks pressure test recording and data logging if the gauge is outside its programmed calibration window, ensuring measurement integrity and compliance.
Tamper-Proof Design: Built-in safeguards to prevent unauthorized alterations to recorded data, supporting audit-ready reporting directly from the gauge.
Operating Temperature Range: -4°F to 140°F, ensuring reliable performance in a wide variety of environmental conditions.
Storage Temperature Range: -4°F to 140°F, for safe long-term storage without compromising functionality.
Humidity Tolerance: ≤ 80% relative humidity, suitable for use in moderately humid settings.
*Requires use of VeriGauge service
